BE9300 Tri-Band Wi-Fi 7: 5760 Mbps (6 GHz) + 4320 Mbps (5 GHz) + 574 Mbps (2.4 GHz). Buffering will no longer be a problem.
-
1× 10G Port: Unlock the full potential of Wi-Fi 7.
-
Clear 6 GHz Band: Brings cleaner and wider band resources to your Wi-Fi.
-
320 MHz Bandwidth: Up to 320 MHz bandwidth enables many more simultaneous transmissions at the fastest possible speeds.
-
Low Latency and Interference: Multi-Link Operation, and Multi-RUs ensure high performance of your network.
-
Advanced Functions: Supports centralized management, mesh, and AI roaming.
TP-LINK EAP773 BE9300 Ceiling Mount Tri-Band Wi-Fi 7 Wireless Access Point 1× 10G Port
TP-LINK EAP773 BE9300 Ceiling Mount Tri-Band Wi-Fi 7 Wireless Access Point 1× 10G Port
TP-LINK BE9300 Ceiling Mount Tri-Band Wi-Fi 7 Wireless Access Point 1× 10G Port (EAP773)
1 × 4.0 dBi, Bluetooth 5.2, 1× 10G Ethernet Port, Ceiling/Wall Mounting(Kits Included)
SPECIFICATIONS
HARDWARE FEATURES
INTERFACE: 1× 10G Ethernet Port
BUTTON: Reset
POWER SUPPLY: 802.3bt PoE or 12V/2.5A DC
POWER CONSUMPTION
Support Smart Power Comsuption Management:
• 24.05 W (802.3bt, full functionality);
• 20.92 W (12/2.5A, full functionality);
• 22.4 W (802.3at decrease 6GHz Power);
• 10.1. W (802.3af, radio off, only main chip and LAN working)
DIMENSIONS ( W x D x H): 8.7 × 8.7 × 1.3 in (220 × 220 × 32.5 mm)
ANTENNA TYPE
• 2.4 GHz: 2× 3.0 dBi
• 5 GHz: 2× 3.0 dBi
• 6 GHz: 2× 3.0 dBi
BLUETOOTH: 1 × 4.0 dBi, Bluetooth 5.2 *Firmware update may be required.
MOUNTING: Ceiling / Wall Mounting (Kits Included)
WIRELESS FEATURES
COVERAGE: 140㎡(1500 ft²)§
WIRELESS CLIENT CAPACITY
• 2 GHz: 128**
• 5 GHz: 128**
• 6 GHz: 128**
CONCURRENT CLIENTS: 380+**
WIRELESS STANDARDS: IEEE 802.11 a/b/g/n/ac/ax/be
FREQUENCY: 6 GHz, 5 GHz, and 2.4 GHz
SIGNAL RATE: 574 Mbps (2.4 GHz) + 2880 Mbps (5 GHz) + 5760 Mbps (6 GHz)
WIRELESS FUNCTIONS
• MLO‡
• 4K-QAM‡
• MU-MIMO‡
• HE320‡
• Mesh△
• BBS Coloring‡
• OFDMA‡
• Load Balance
• Band Steering
• Beamforming
• Airtime Fairness
• Multiple SSIDS:24(8 on each band)
• Wireless Schedule
• Reboot Schedule
• QoS(WMM)
• Rate Limit
• Static IP/Dynamic IP
• RADIUS Accounting
• MAC Authentication
WIRELESS SECURITY
• Captive Portal Authentication△
• Access Control
• Maximum number of MAC Filter: 4,000
• Wireless Isolation Between Clients
• VLAN
• Rogue AP Detection
• WPA-Personal/Enterprise, WPA2-Personal/Enterprise, WPA3-Personal/Enterprise
TRANSMISSION POWER
< 20 dBm (2.4 GHz, EIRP)
< 23 dBm (5 GHz, band 1&band 2, EIRP)
< 28 dBm (5 GHz, band 3, EIRP)
< 23dBm (6 GHz, EIRP)
MANAGEMENT
OMADA APP: Yes
CENTRALIZED MANAGEMENT
• Omada Cloud-Based Controller
• Omada Hardware Controller (OC300)
• Omada Hardware Controller (OC200)
• Omada Software Controller
CLOUD ACCESS: Yes. Require the use of an OC300, OC200, Omada Software Controller, or an Omada Cloud-Based Controller.
EMAIL ALERTS: Yes
LED ON/OFF CONTROL: Yes
MANAGEMENT MAC ACCESS CONTROL: Yes
SNMP: v1, v2c, v3
SYSTEM LOGGING LOCAL/REMOTE SYSLOG: Yes
WEB-BASED MANAGEMENT: Yes
OTHERS
CERTIFICATION: CE, FCC, RoHS, IC
PACKAGE CONTENTS
• EAP773
• Installation Guide
• Ceiling/Wall Mounting Kits
Note: Power Adapter is NOT included.
ENVIRONMENT
• Operating Temperature: 0 °C–40 °C (32 °F–104 °F);
• Storage Temperature: -40 °C–70 °C (-40 °F–158 °F);
• Operating Humidity: 10%–90% non-condensing;
• Storage Humidity: 5%–90% non-condensing;
