HARDWARE FEATURES
INTERFACE: 1× Gigabit Ethernet (RJ-45) Port
BUTTON: Reset
POWER SUPPLY
• 802.3at PoE
• 48 V Passive PoE
• 12 V / 1 A DC (Power Adapter IS NOT included)
POWER CONSUMPTION
• 11.0W (For PoE);
• 9.9W (For DC)
DIMENSIONS ( W x D x H ): V2 and above: 6.3 × 6.3 × 1.3 in (160 × 160 × 33.6 mm)
ANTENNA TYPE
Internal Omni Antenna
• 2.4 GHz: 2× 4 dBi
• 5 GHz: 2× 5 dBi
MOUNTING
• Ceiling /Wall Mounting (Kits included)
• Junction Box Mounting
WIRELESS FEATURES
WIRELESS CLIENT CAPACITY: 250+**
WIRELESS STANDARDS: IEEE 802.11ax/ac/n/g/b/a
FREQUENCY: 2.4 GHz and 5 GHz
SIGNAL RATE
• 5 GHz: Up to 1201 Mbps
• 2.4 GHz: Up to 574 Mbps
WIRELESS FUNCTIONS
• 1024-QAM
• 4× Longer OFDM Symbol
• OFDMA
• Multiple SSIDs (Up to 16 SSIDs, 8 for each band)
• Enable/Disable Wireless Radio
• Automatic Channel Assignment
• Transmit Power Control (Adjust Transmit Power on dBm)
• QoS(WMM)
• MU-MIMO
• Seamless Roaming §
• Omada Mesh§
• Band Steering
• Load Balance
• Airtime Fairness
• Beamforming
• Rate Limit
• Reboot Schedule
• Wireless Schedule
• Wireless Statistics based on SSID/AP/Client
WIRELESS SECURITY
• Captive Portal Authentication§
• Access Control
• Wireless Mac Address Filtering
• Wireless Isolation Between Clients
• SSID to VLAN Mapping
• Rogue AP Detection
• 802.1X Support
• WPA-Personal/Enterprise, WPA2-Personal/Enterprise, WPA3-Personal/Enterprise
TRANSMISSION POWER
• CE:
<20 dBm(2.4 GHz, EIRP)
<23 dBm(5 GHz band1/2, EIRP) <25 dBm (5 GHz band3)
• FCC:
<25 dBm (2.4 GHz)
<25 dBm (5 GHz)
MANAGEMENT
OMADA APP: Yes
CENTRALIZED MANAGEMENT
• Omada Cloud-Based Controller
• Omada Hardware Controller OC300
• Omada Hardware Controller OC200
• Omada Software Controller
CLOUD ACCESS: Yes, through
• OC300
• OC200
• Omada Software Controller
• Omada Cloud-Based Controller
EMAIL ALERTS: Yes
LED ON/OFF CONTROL: Yes
MANAGEMENT MAC ACCESS CONTROL: Yes
SNMP: v1, v2c, v3
SYSTEM LOGGING LOCAL/REMOTE SYSLOG: Local/Remote Syslog
SSH: Yes
WEB-BASED MANAGEMENT: HTTP/HTTPS
L3 MANAGEMENT: Yes
MULTI-SITE MANAGEMENT: Yes
MANAGEMENT VLAN: Yes
ZERO-TOUCH PROVISIONING: Yes. Requiring the use of Omada Cloud-Based Controller
OTHERS
CERTIFICATION: CE, FCC, RoHS
PACKAGE CONTENTS
• EAP613
• Ceiling/ Wall Mounting Kits
• Installation Guide
SYSTEM REQUIREMENTS: Microsoft Windows XP, Vista, Windows 7, Windows 8, Windows10, Windows11, Linux
ENVIRONMENT
• Operating Temperature: 0–40 ℃ (32–104 ℉)
• Storage Temperature: -40–70 ℃ (-40–158 ℉)
• Operating Humidity: 10–90% RH non-condensing
• Storage Humidity: 5–90% RH non-condensing
†Maximum wireless signal rates are the physical rates derived from IEEE Standard 802.11 specifications. Actual wireless data throughput and wireless coverage are not guaranteed and will vary as a result of 1) environmental factors, including building materials, physical objects, and obstacles, 2) network conditions, including local interference, volume and density of traffic, product location, network complexity, and network overhead, and 3) client limitations, including rated performance, location, connection, quality, and client condition.
‡Use of Wi-Fi 6 (802.11ax), and features including OFDMA and MU-MIMO require clients to also support the corresponding features.
§Omada Mesh, Seamless Roaming, Captive Portal, and Cloud Access require the use of Omada SDN controllers. Please go to https://www.tp-link.com/en/omada-mesh/product-list/ to find all the models supported by Omada mesh technology, and refer to the User Guides of Omada SDN controllers for configuration methods.
*Zero-Touch Provisioning and Auto Channel Selection and Power Adjustment require the use of Omada Cloud-Based Controller. Please go to https://www.tp-link.com/en/omada-cloud-based-controller/product-list/ to confirm which models are compatible with Omada Cloud-Based Controller.
**The actual capacity depends on the wireless environment and client traffic and is generally less than the maximum number of client connections.
