Seasonic FOCUS SPX-750 (2021) 80 Plus® Platinum Certified Fully Modular SFX Power Supply - Hybrid Silent Fan Control, SFX to ATX Bracket (10 Year Warranty)

SEASONIC FOCUS SPX (2021)

The new line of Seasonic's FOCUS SPX is versatile in its application and powerful with a small footprint. It is a standard SFX unit, measuring at 125 mm (L) x 100 mm (W) x 63.5 mm (H). The FOCUS SPX (2021) is shipped with an SFX to ATX adapter bracket in the box, which allows the power supply to be mounted not only in the SFX form factor chassis, but also a standard ATX chassis should the user prefers to reserve more space for airflow inside the PC case. The Seasonic hybrid fan control is always enabled to optimize the cooling according to necessity.

• 80 PLUS® Platinum certified
• Compact SFX Size - 125 (L) x 100 (W) x 63.5 (H) mm
• Tight Voltage Regulation
• Cable-free Connection Design
• S3FC - Fanless until 30 % load
• SFX to ATX Expandability
• Gold plated connectors
• 10 years warranty

SPECIFICATIONS

MODEL: FOCUS-SPX-750-2021

TECHNICAL SPECIFICATIONS

80PLUS®: Platinum
CYBENETICS EFFICIENCY LEVEL: TBA
CYBENETICS NOISE LEVEL: TBA
FORM FACTOR: Intel SFX 12 V / ATX 12 V
DIMENSIONS: 100 mm (L) x 125 mm (W) x 63.5 mm (H)

FAN INFORMATION

• Fan Size : 92 mm
• Fan Control : Premium Hybrid Fan Control
• Fan Bearing : Fluid Dynamic Bearing
• Life Expectancy : 50,000 hours at 40 °C, 15 % - 65 % RH

CABLE INFORMATION

• Modularity : Fully Modular
• Cable type : Flat black cables

ELCTRICAL FEATURES

• Operating Temperature : 0 - 50 °C (derating from 100 % to 80 % from 40°C to 50°C)
• MTBF @ 25 °C, excl. fan : 100,000 hours
• AC Input : Full Range
• Protection : OPP, OVP, UVP, OCP, OTP, SCP

SAFETY AND ENVIRONMENTAL

• Safety and EMC : cTUVus, TUV, CB, CCC, BSMI, EAC, CE
• Environmental Compliance : Energy Star, RoHS, WEEE, ErP Lot 6, REACH

WARRANTY: 10 Years

POWER OUTPUT

AC INPUT
• Voltage: 100 V - 240 V
• Current: 10 - 5 A
• Frequency: 50 Hz - 60 Hz
