Intel Core i5-14500 Core i5 14th GEN CPU Processor
ESSENTIALS
• Product Collection : Intel® Core™ i5 Processors (14th gen)
• Code Name : Products formerly Raptor Lake
• Vertical Segment : Desktop
• Processor Number : i5-14500
• Lithography : Intel 7
• Use Conditions : PC/Client/Tablet, Workstation
CPU SPECIFICATIONS
• Total Cores : 14
• # of Performance-cores : 6
• # of Efficient-cores : 8
• Total Threads : 20
• Max Turbo Frequency : 5 GHz
• Performance-core Max Turbo Frequency : 5 GHz
• Efficient-core Max Turbo Frequency : 3.7 GHz
• Performance-core Base Frequency : 2.6 GHz
• Efficient-core Base Frequency : 1.9 GHz
• Cache : 24 MB Intel® Smart Cache
• Total L2 Cache : 11.5 MB
• Processor Base Power : 65 W
• Maximum Turbo Power : 154 W
GPU SPECIFICATIONS
• GPU Name‡ : Intel® UHD Graphics 770
• Graphics Max Dynamic Frequency : 1.55 GHz
• Graphics Output : eDP 1.4b, DP 1.4a, HDMI 2.1
• Execution Units : 32
• Max Resolution (HDMI)‡ : 4096 x 2160 @ 60Hz
• Max Resolution (DP)‡ : 7680 x 4320 @ 60Hz
• Max Resolution (eDP - Integrated Flat Panel)‡ : 5120 x 3200 @ 120Hz
• DirectX* Support : 12
• OpenGL* Support : 4.5
• OpenCL* Support : 3.0
• Multi-Format Codec Engines : 2
• Intel® Quick Sync Video : Yes
• Intel® Clear Video HD Technology : Yes
• # of Displays Supported ‡ : 4
• Device ID : 0x4680
