ASUS ROG MAXIMUS Z790 DARK HERO Motherboard + Intel i7-14700K / i7-14700KF (14th GEN) Processor BUNDLE
ASUS ROG MAXIMUS Z790 DARK HERO Motherboard + Intel i7-14700K / i7-14700KF (14th GEN) Processor BUNDLE
Regular price
$1,870.00 SGD
Regular price
Sale price
$1,870.00 SGD
Unit price
/
per
ROG Maximus Z790 Dark Hero
Intel® Z790 Chipset
The ROG Maximus Z790 Dark Hero boasts robust cooling, WiFi 7 and ample PCIe 5.0 slot for unmatched performance, and it offers full compatibility with 14th Gen Intel® Core™ processors. Meanwhile, its stealthy design is accentuated by new Polymo lighting, which illuminates the I/O shroud with a microstructural array of dual-layer RGB and adds a personalized touch of style to your gaming setup. This platform delivers the power and connectivity that advanced AI PC applications demand.
- EXTENSIVE GEN 5 - x1 onboard M.2 slot, and x2 PCIe 5.0 x16 slots
- DDR5 - MAX. 192GB, DIMM FLEX, AEMP II
- WIFI 7 - Next-gen WiFi 7* chipset introduces all-new ultrawide 320 MHz channel bandwidth in the 6 GHz band and 4096 QAM, delivering up to 2.4X ultra-fast WiFi speeds**. The revolutionary Multi-Link Operation (MLO) provides a more stable WiFi connection and lower latency, unlocking the realms of the unknown in gaming, streaming, and industrial IoT.
- 2.5Gb ETHERNET - Low-latency gaming, speedy file transfers, and high-resolution video streaming are among the many perks of onboard Intel® 2.5 Gbps Ethernet.
- AI OVERCLOCKING - Tuning is now faster and smarter than ever before. ASUS AI Overclocking profiles the CPU and cooling to predict the optimal configuration and push the system to its limits. Predicted values can be engaged automatically or used as a launching ground for further experimentation.
- AI COOLING II - One-click fan tuning
-
Teamed Power Solution 20+1+2
- DIY - Friendly Design
- POLYMO Lighting
-
TWO THUNDERBOLT 4 TYPE-C® PORTS - Each port delivers up to 40 Gbps of bidirectional bandwidth for the latest super-speed devices and drives. Both ports can be employed for up to two external 4K displays, and PCIe bandwidth extends to up to 32 Gbps.
Intel® Core™ i7-14700K / i7-14700KF
(33M Cache, up to 5.60 GHz)
CPU Specifications
- Total Cores - 20
- # of Performance-cores - 8
- # of Efficient-cores - 12
- Total Threads - 28
- Max Turbo Frequency - 5.6 GHz
- Intel® Turbo Boost Max Technology 3.0 Frequency ‡ - 5.6 GHz
- Performance-core Max Turbo Frequency - 5.5 GHz
- Efficient-core Max Turbo Frequency - 4.3 GHz
- Performance-core Base Frequency - 3.4 GHz
- Efficient-core Base Frequency - 2.5 GHz
- Cache - 33 MB Intel® Smart Cache
- Total L2 Cache - 28 MB
- Processor Base Power - 125 W
- Maximum Turbo Power - 253 W
Memory Specifications
- Max Memory Size (dependent on memory type) - 192 GB
- Memory Types - Up to DDR5 5600 MT/s, Up to DDR4 3200 MT/s
- Max # of Memory Channels - 2
- Max Memory Bandwidth - 89.6 GB/s
- ECC Memory Supported ‡ - Yes (i7-14000K) / No (i7-14700KF)
GPU Specifications (i7-14700K)
- GPU Name‡ - Intel® UHD Graphics 770
- Graphics Base Frequency - 300 MHz
- Graphics Max Dynamic Frequency - 1.6 GHz
- Graphics Output - eDP 1.4b, DP 1.4a, HDMI 2.1
- Execution Units - 32
- Max Resolution (HDMI)‡ - 4096 x 2160 @ 60Hz
- Max Resolution (DP)‡ - 7680 x 4320 @ 60Hz
- Max Resolution (eDP - Integrated Flat Panel)‡ - 5120 x 3200 @ 120Hz
- DirectX* Support - 12
- OpenGL* Support - 4.5
- OpenCL* Support - 3.0
- Multi-Format Codec Engines - 2
- Intel® Quick Sync Video - Yes
- Intel® Clear Video HD Technology - Yes
- # of Displays Supported ‡ - 4
- Device - ID0xA780
Expansion Options
- Direct Media Interface (DMI) Revision - 4.0
- Max # of DMI Lanes - 8
- Scalability - 1S Only
- PCI Express Revision - 5.0 and 4.0
- PCI Express Configurations ‡ - Up to 1x16+4, 2x8+4
- Max # of PCI Express Lanes - 20
Package Specifications
- Sockets Supported - FCLGA1700
- Max CPU Configuration - 1
- Thermal Solution Specification - CG 2020A
- TJUNCTION - 100 °C
- Package Size - 5.0 mm x 37.5 mm
- Max Operating Temperature - 100 °C
Advanced Technologies
- Intel® Volume Management Device (VMD) - Yes
- Intel® Gaussian & Neural Accelerator - 3.0
- Intel® Thread Director - Yes
- Intel® Deep Learning Boost (Intel® DL Boost) on CPU - Yes
- Intel® Speed Shift Technology - Yes
- Intel® Turbo Boost Max Technology 3.0 ‡ - Yes
- Intel® Turbo Boost Technology ‡ - 2.0
- Intel® Hyper-Threading Technology ‡ - Yes
- Intel® 64 ‡ - Yes
- Instruction Set - 64-bit
- Instruction Set Extensions - Intel® SSE4.1, Intel® SSE4.2, Intel® AVX2
- Idle States - Yes
- Enhanced Intel SpeedStep® Technology - Yes
- Thermal Monitoring Technologies - Yes
Security Reliability (i7-14700K)
- Intel vPro® Eligibility ‡ - Intel vPro® Enterprise, Intel vPro® Essentials, Intel vPro® Platform
- Intel® Threat Detection Technology (TDT) - - Yes
- Intel® Active Management Technology (AMT) ‡ - Yes
- Intel® Standard Manageability (ISM) ‡ - Yes
- Intel® Remote Platform Erase (RPE) ‡ - Yes
- Intel® One-Click Recovery ‡Yes Intel® Hardware Shield Eligibility ‡ - Yes
- Intel® Control-Flow Enforcement Technology - Yes
- Intel® Total Memory Encryption - Multi Key - Yes
- Intel® AES New Instructions - Yes
- Secure Key - Yes
- Intel® OS Guard - Yes
- Intel® Trusted Execution Technology ‡ - Yes
- Execute Disable Bit ‡ - es
- Intel® Boot Guard - Yes
- Mode-based Execute Control (MBEC) - Yes
- Intel® Stable IT Platform Program (SIPP) - Yes
- Intel® Virtualization Technology with Redirect Protection (VT-rp) ‡ - Yes
- Intel® Virtualization Technology (VT-x) ‡ - Yes
- Intel® Virtualization Technology for Directed I/O (VT-d) ‡ - Yes
- Intel® VT-x with Extended Page Tables (EPT) ‡ -Yes
Security Reliability (i7-14700KF)
- Intel® Standard Manageability (ISM) ‡ - Yes
- Intel® Control-Flow Enforcement Technology - Yes
- Intel® AES New Instructions - Yes
- Secure Key - Yes
- Intel® OS Guard - Yes
- Execute Disable Bit ‡ - Yes
- Intel® Boot Guard - Yes
- Mode-based Execute Control (MBEC) - Yes
- Intel® Virtualization Technology (VT-x) ‡ - Yes
- Intel® Virtualization Technology for Directed I/O (VT-d) ‡ - Yes
- Intel® VT-x with Extended Page Tables (EPT) ‡ Yes
