Form Factor
Mid Tower
Material
SGCC sheet metal, tempered glass, ABS, Nylon, Silicon, Zinc alloy, NdFeB magnets
PC Case Dimensions (L x W x H)
541 x 259.5 x 547 mm
Net Weight
19 kg
Warranty 3 years
Front I/O
USB 3.2 Gen 2 Type-C x1
USB 3.2 Gen 1 Type-A x2
Audio Jack x1
Power & Reset Button x1
Motherboard Support
E-ATX (Max Width 277 mm) / ATX / M-ATX / Mini-ITX
Expansion Slots
6 horizontal, 4 vertical
Fan Support
Maximum Amount: 11
Top: 3 x 120 / 3 x 140 mm
Right: 3 x 120 / 3 x 140 mm
Bottom: 3 x 140 mm
Rear: 2 x 120 / 2 x 140 mm (Thickness Up to 30 mm)
Fan PWM Repeater
Channel: Total 12 ch
Location: Cable Management Tray x1
PSU shroud x1
CPU Tower Cooler Clearance
Height: Up to 185 mm. Tower cooler size depends on GPU width. CPU center to graphics card PCIe edge connector; ~199mm (varies by motherboard). Liquid cooling recommended.
Liquid Cooling Support
Top: 280 / 360 / 420 mm (Thickness: 65 mm, not overlapping with RAM)
Right: 280 / 360 / 420 mm (Thickness: 60 mm w/ GPU >317mm, 80 mm w/ top AIO)
Graphics Card Clearance
Length: Up to 470 mm
Width: Up to 195 mm. GPU width support depends on CPU cooler size. CPU center to graphics card PCIe edge connector: ~199mm (varies by motherboard). Liquid cooling recommended.
Vertical GPU Support
4 Slots
PCI Express 5.0 Riser Cable Included
RAM Clearance
If the fan and radiator thickness is greater than 65 mm: 420 mm - 32 mm / 360 mm - 43 mm
Power Supply Support
ATX / SFX / SFX-L PSUs
Length: Up to 220mm (Clearance - 290mm)
Storage
Right Fan Mount: 4 Storage Bays: 4 x 3.5'' / 8 x 2.5''
Cable Management Tray: 1 Storage Bay: 1 x 3.5'' / 2 x 2.5''
Storage Bay Included: 4x
Internal Display Support
VESA Mounting: 75 x 75 mm / 100 x 100 mm
Display Size: 14 in. (Max)
Location: Front Right Pillar
Dust Filter
Bottom: 1 (Removable)
Top: 1 (Built-in)
Right: 1 (Built-in)
Rear Bottom: 1 (Removable)
